Samsung Kiosk | Connection Box

The Samsung Kiosk Connection Box is a modular accessory designed for Samsung self-service kiosk displays. It acts as the central hub that connects the kiosk display to essential peripherals such as payment terminals, printers, and network devices.

Designed for modern retail and hospitality environments, the connection box enables businesses to build fully functional self-service kiosks with payment, printing, and barcode scanning capabilities. The compact design integrates easily with the Samsung Kiosk display and stand, allowing for clean cable management and streamlined installation.

The system supports multiple payment methods including credit cards, QR codes, barcodes, and NFC, making it suitable for ordering kiosks, ticketing systems, and self-checkout stations. The integrated thermal printer allows businesses to print receipts directly from the kiosk without requiring external devices.

General
Product Type: Kiosk connectivity and peripheral control box
Model Number: CY-KM24APXEN
Colour: White
Designed For: Samsung self-service kiosk systems

Connectivity
One Connect Port: 1 × 44-pin bi-direction connection port
USB Ports: 3 × USB ports
External Control Ports: 3 × RS-232C control ports
Network Port: 1 × RJ45 Ethernet output for EFT terminal connection

Receipt Printer
Printer Type: Thermal receipt printer
Printing Speed: 250 mm per second
Automatic Cutting: Supports full cut and partial cut
Paper Support: 80 mm paper roll
Supported Paper Width: 20 – 83 mm
Paper Thickness: 0.05 – 0.12 mm

Barcode / QR Code Reader
Supported Codes: 1D and 2D barcode formats
Readable From: Mobile screens and printed barcodes
Supported Formats: UPC-A, UPC-E, EAN-8, EAN-13, Code 128, Code 39, Code 93, Interleaved 2 of 5, GS1 DataBar, Codabar, QR Code

Dimensions
Product Dimensions (W × H × D): 334.4 × 389.6 × 236.5 mm
Package Dimensions (W × H × D): 428 × 471 × 316 mm

Weight
Product Weight: 7.4 kg
Package Weight: 9.1 kg

Typical Applications
Retail self-checkout kiosks
Restaurant self-ordering systems
Ticketing machines
Airport and transport kiosks
Customer service kiosks

2 year warranty
